Shore Power Plug & Socket
BFMP series cable plug&sockets is used to connect the shore power to the ship when ship docked. BFMP plug & socket connection can be completed in a short time to connect or disconnect, easy to operate. BFMP plug & socket with signal detection function, to a great extent to ensure the safety.
Technical Features
|
Operating Voltage |
440V |
690V |
1100V |
7.2KV |
12KV |
|
Power Capacity |
63A 125A 200A 250A 320A 420A |
250A 320A 350A 420A |
660A |
350A |
500A |
|
IP Rating |
IP66 |
||||
|
Material |
Cast aluminum enclosure + anti-corrosion spray,beryllium copper circlip |
||||
|
Standard |
IEC80005,IEC62613 |
||||
|
Product Characteristics |
? The plug and socket can be used for mutual connection with other brand products that meet IEC standards ? Pin spring: beryllium copper, good elasticity, strong and light, the structure of the table chain, increase the plug and jack contact area, reduce the temperature rise ? Contacts and terminals are connected with standard threads to increase the contact area ? With mechanical safety, fixed device, with mechanical anti- dislocation structure and ground interlocking device ? With push-pull handle, improve the convenience of connection |
||||
